Connecting Dinse FD300 welding torch (R500 WF HD EUR+ )
This section describes how to connect the Dinse FD300 welding torch to R500 Wire Feeder HD EUR+. For more information on the wire feeder control cable connector, refer to Push-pull welding torch control cable connector.
The Dinse FD300 control cable connector does not fit the R500 Wire Feeder HD EUR+ directly. Therefore, there are two options for connecting:
| • | The Dinse FD300 control cable connector is replaced with connectors suitable for R500 Wire Feeder HD EUR+. These control cable connectors can be ordered from Kemppi.com. |
| • | An adapter is used between Dinse FD300 and R500 Wire Feeder HD EUR+ (not available in the Kemppi product range). |
The following illustrates the connection of Dinse FD300 welding torch to R500 Wire Feeder HD EUR+:
