Wire feeder navigation

The three main views on the wire feeder display are the same as in Control Pad: Channel, Welding, and Settings.

You can press the Power button to lock the wire feeder and avoid starting welding accidentally.

The wire feeder has a memory channels button on the left and the Settings button on the right side of the display. Press these buttons to change the view on the wire feeder's display. Press the button again to return to the Welding view.

Use the knobs under the display to move focus in the display and to adjust the values. When there is a green light in the center of the knob, the knob also functions as a push button.

In the Welding view, adjust the welding power with the left knob and the fine tuning with the right knob. In most welding processes, this secondary parameter is voltage.

In all other views, move up and down in the menus with the right knob. Press the green button in the center of the knob to open an item.
