WLAN access point mode

Access point mode is the default WLAN operating mode. In this mode DCM 2.0 acts as an access point to which other devices (PC, mobile device) can connect. For information on network settings, refer to Network settings.

The DCM 2.0 security code (1) and serial number (2) can be found in the rating plate on the DCM 2.0 device.

1.

Connect your device to the WLAN network.

>>  The WLAN default name (SSID) is DCM<DCM serial number>, e.g., DCM1234567​.

>>  The default password is KemppiDCM<DCM security code>, e.g., KemppiDCM1234.

2.

Once connected (connecting may take a few seconds), open an internet browser and enter the default network address.

>>  The network address for DCM 2.0 is DCM<DCM serial number.local, e.g., DCM1234567.local.​

>>  You are now connected to the DCM 2.0 user interface.

If the default network address does not work, use the numeric IP address (192.168.3.1).
